| Chip: | M10(10th Generation Chip) |
| Frequency: | GPS L1，GLONASS L1，BDS B1，GALILEO， ESBAS L1，QZSS L1 |
| Input Voltage: | 5V |
| Antenna: | Ceramic Antenna |
| Channel: | 72 |
| Battery: | Bilid-in |
| Compass: | QMC5883 |
| Compass Orientation: | Plug facing direction of flight and obviously antenna up, BF: CW 90° Flip |
| Baud Rate: | 115200bps |
| Protocol: | Dual NMEA/UBLOX |
| Output Frequency: | 1Hz-10Hz,10Hz default |
| Speed Accuracy: | 0.05m/s |
| Horizontal Positioning Accuracy: | 2D ACC1.5m(outdoor) |
| Receiver Sensitivity: | Trace -166dBm; Capture -160dBm |
| Dynamic Characteristics: | Height 50000m; Speed 500m/s; Acceleration 4G |
| Operating Temperature: | -40C-+85C |
| Storage temperature: | -40C-+105C |
| Weight: | 12g |
| Size: | 25*25*8mm |
